Industrial diesel driven mobile screw air compressor machine

FOB Reference Price:Get Latest Price
US $5,000-50,000 / Set | 1 Set/Sets Industrial diesel driven mobile screw air compressor machine (Min. Order)
Supply Ability:
100 Set/Sets per Month Industrial diesel driven mobile screw air compressor machine
Port:
shanghai
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Screw
Configuration:
Portable
Power Source:
Diesel
Lubrication Style:
Lubricated
Mute:
Low noise
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
DENAIR
Model Number:
DACY-series
Voltage:
diesel engine driven
Dimension(L*W*H):
3400*1720*2610mm
Weight:
900~6900kg
Certification:
ISO9001/GC/CE/SGS
Warranty:
2 Years
After-sales Service Provided:
Engineers available to service machinery overseas
product name:
Industrial diesel driven mobile screw air compressor machine
Application:
Drilling Operations; hydroblasting; cable blowing and so on
Diesel engine:
Cummins or Yangdong
normal working pressure:
7~35bar
Inlet air valve:
Austria Hoerbigger
pressure valve:
Denmark Denfoss
free air delivery:
3.2~45m3/min
weight:
900~6900kg
With shell:
water, dust, noise proof
dimensions(L*W*H):
3400*1720*2610mm
Packaging & Delivery
Packaging Details
seaworthy packing for Industrial diesel driven mobile screw air compressor machine
Delivery Time
15days after receiving the prepayment.
Video Description

Industrial diesel driven mobile screw air compressor machine

Products Description

Product Advantages

1.Easy to move (accept skid-mounted customization)

2.Large volume fuel tank to ensure 10 hours/day workload.

3.A wide range of pressure and capacity design, 57 models for customers to choose.

4.Butterfly inlet valve to achieve 0 ~ 100% continuous automatic flow control.

5.Double damping of the main engine and axle, the machine runs more smoothly.

6.Large area cooler design, rust-proof resin fan.

7.Choose the best matching power Diesel Engine to reduce overall operating load and increase service life.

Technical Prameters

DENAIR hot sale series diesel portable air compressors
ModelMachineDiesel Engine

Free Air

Delivery

Normal

Working Pressure

Dimensions
    (without towbar)
Weight Manufacturer Model

Rated

power

 m3/minCFMbar(e)psigL*W*H(mm)kgKW
DACY-3.2/83.9814081162265*1590*1575900yangdongYSD490G32
DACY-5/75.7220271023075*1900*20401350CumminsQSB3.9-C80-31 60
DACY-6/75.7220271023075*1900*20401350QSB3.9-C80-3160
DACY-7.5/77.50 26571023075*1900*20401350QSB3.9-C80-3160
DACY-12/712.00 42471023220*2000*23551700QSB3.9-C130-3196
DACY- 8.5/1010.28363101453220*2000*23551700QSB3.9-C130-3196
DACY-13/813.00 45981163530*2090*23252050QSB5.9-C150-31113
DACY-11/1011.27398101453530*2090*23252050QSB5.9-C150-31113
DACY-10/1310.05355131893530*2090*23252050QSB5.9-C150-31113
DACY-9/149.00 318142033530*2090*23252050QSB5.9-C150-31113
DACY-14/1214.00 494121753400*1770*26703600QSB5.9-C180-31132
DACY-10/2012.52 442202903400*1770*26704000QSC8.3-C215-30160
DACY-22.5/14G22.50 794142033820*1980*26804400QSL8.9-C325-30239
DACY-22/2022.00 777202904000*2300*27505500QSL8.9-C360-30264
DACY-32/1032.00 1130101454720*2160*32005500QSZ13-C400-30298
DACY-45/1047.771687101454720*2160*32006500QSB5.9-C150-31415
DACY-33/3533.481182355084510*2160*31706900KTA19-P700522
*)Free air delivery in accordance with ISO 1217 :2009, Annex C: Absolute intake pressure 1 bar(a), cooling and air take tempetature 20 ℃.
Note: Skid-mounted type is available.

(Specifications are subject to change without prior notice)

40 more models, pls inquire to us online!

Project Case

Packaging & Shipping



DENAIR Certificates



About DENAIR





Pls feel free to chat with us online or send your inquiry, including your company name, email address and phone number below!

FAQ



1.How long is your air compressor warranty?

Answer1 year.



2.Do you provide After- sales service parts?

AnswerOf course, We could provide easy- consumable spares.



3.How long could your air compressor be used?

Answer:  Generally, more than 10 years.



4.How about your price?

AnswerBased on high quality, Our price is very competitive in the world



5.How about your customer service?

AnswerFor email, we could reply our customers' emails within 2 hours.
